Product Description

HBS series of medium and high power three in three out intelligent uninterruptible power supply, single capacity from 6KVA to 400KVA, the product is a digital, information, networked as one of the highly intelligent power supply products, the use of high-speed microprocessor (MCU) and ASIC DDC control technology, with powerful information acquisition system, signal processing system, monitoring system and perfect protection system; widely It is widely used in various power-using environments, such as high-rise buildings, road lighting, electric power, industrial and mining enterprises, network computer rooms and other industries. Personalised design, friendly human-machine interaction, intuitive Chinese and English colour display and status indication monitoring interface make it easy for users to operate and use. (Three in, three out)

Product features

Intelligent digital control technology.

High-speed microcontrollers and programmable logic devices are used for circuit control, parameter setting, operation management, advanced self-test and self-detection functions for all individual circuit connections on the board and fault analysis. (You can rely on digitally converted sine wave voltages and new solutions for perfect operation: for your real needs.)

Highly efficient IGBT (Insulated Gate Bipolar Transistor) inverter technology.

Good high-speed switching characteristics of IGBTs; high voltage and high current operating characteristics; voltage-based drive, requiring only a small amount of control power. The fifth generation of IGBTs has a lower saturation voltage drop, higher efficiency and reliability of the inverter.

Flexible parallel technology.

Suitable for single, 1+1 parallel and N+1 parallel redundancy of systems with different loads.

Excellent load characteristics.

With three-phase fully independent PWM modulation and full-bridge IGBT inverter technology, it fully satisfies the jump from 0 to 100% load without switching to bypass and protects the stable and reliable output.

User-friendly 7" large LCD colour touch screen in English and Chinese.

7" large screen LCD Chinese and English menu, flow chart operation status intuitive display, flexible human-machine dialogue function, touch screen with event record display, Chinese and English language selectable menu operation.

Complete protection functions.

Input and output over- and under-voltage protection, input surge protection, phase sequence protection, battery overcharge and over-discharge protection, output overload and short-circuit protection, over-temperature protection and many other system protection and alarm functions.

High performance dynamic characteristics.

A variety of feedback controls, such as instantaneous control mode and rms value, are used to achieve high dynamic regulation and reduce voltage distortion.

6 pulses (12 pulses optional)

The rectifier charger also adds an input harmonic filter to effectively suppress input harmonic pollution, improve the input power factor of the UPS power supply and reduce the input harmonic current.

Intelligent battery management.

Intelligent battery charging, which automatically adjusts the charging parameters of the battery according to the user's battery configuration, and will convert the battery to even charge float charge, temperature compensated charging, and discharge management according to the supply environment, extending the life of the battery and reducing the burden on the administrator.

Complete isolation technology

Input and output are completely isolated to reduce harmonic currents and direct interference from the mains.

Intelligent communication management.

RS232 and RS485 communication ports for true multi-purpose communication and remote monitoring, optional SNMP card for remote monitoring and network management, optional dry contact interface with passive contact to achieve status monitoring of the UPS.

Technical specifications
