Rated Power

500W

Surge Power

1000W(few seconds)

Input Voltage

12VDC

24VDC

24VDC

Output Voltage

220VAC±5%

USB Port

5V 2.4A

Frequency

50Hz±3

Output Waveform

Pure Sine Wave

Soft Start

YES

AC Regulation

THD＜3%(Linear Load)

Output Efficiency

92% MAX

DC Voltage Range

10-15.5V

20-31V

Low Voltage Alarm

10.5±0.5V

21±0.5V

Low Voltage Shut Down

10±0.5V

20±0.5V

Low Voltage Recovery

13±0.5V

24±0.5V

Over Voltage Shut Down

15.5±0.5V

31±0.5V

Over Voltage Recovery

14.8V±0.5V

29V±0.5V

Cooling Way

Intelligent Cooling Fan

Protection

Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit

Working Temperature

-10℃ - +50℃

Net Dimension

240*150*80mm (L×W×H)

Inner Box Dimension

270*150*145mm (L×W×H)

Meas./Ctn

76*45*28cm / 10pcs

N.W./Unit

1.92kg (2.3kg With Inner Box)

G.W./Ctn

24.4KGS

Packing

CARTON

Warranty

2 Years
